Panasonic C-SCP360H38B Scroll Compressor without Valves – 10 HP / 101,700 BTU, R410A

Panasonic Scroll Compressor C-Scp360H38B 10Hp

General Specifications:

• Compressor Power: 10 HP
• Refrigerant: R410A
• Application Type: HBP (High Back Pressure) +7.2℃ / +54.4℃.
• Power Supply: 380-440V, 50-60Hz.

Product Description:

The Panasonic Scroll Compressor C-Scp360H38B, a 10 HP model, stands out for its high energy efficiency and reliable performance. It is ideal for use in various commercial and industrial refrigeration applications.

Applications:

This 10 HP Panasonic Scroll Compressor is generally preferred in places such as large commercial buildings, industrial facilities, cold storage warehouses and shopping malls. It is designed to meet high-capacity cooling requirements.

Manufacturer Technical Data

• Cooling Capacity: 29,804 W = 101,700 BTU/h
• Power Input: 9,899 W — COP: 3.01
• Rated Current: 16.90 A — MCC: 28 A
• Displacement: 120.2 cm³/rev
• Oil Charge: 2.80 L
• Net Weight: 71 kg
• Sound Level: 72 dB
• Power Supply: 380~415 V / 3 phase / 50 Hz
• Refrigerant: R410A

Values are taken from the manufacturer's technical report; test conditions: evaporating 7.2 °C, condensing 54.4 °C, superheat 11.1 K, subcooling 8.3 K.
