Danfoss KP15 Pressure Switch 060-126466 – SPDT+SPST(NO), -0.2 - 32 bar, Automatic/Manual Reset

The Danfoss KP15 (060-126466) model is a professional pressure switch providing advanced dual pressure control, equipped with an SPDT + SPST(NO) dual contact arrangement. With automatic reset on the left side and manual reset on the right side, it increases system safety. It offers high-accuracy control in refrigeration and HVAC applications. Thanks to its IP30 protection class, it is suitable for in-panel installations.

Technical Specifications

• Product Code: 060-126466
• Model: KP15
• Contact Type: SPDT + SPST (normally open)
• Reset Function: Left side: Automatic | Right side: Manual
• Pressure Connection: 1/4" Male flare (DIN 8906)
• Pressure Sensing Element: Bellows

Adjustable Pressure Ranges

• Left Side: -0.2 to 7.5 bar (6 inHg - 108 psig)
• Right Side: 8 to 32 bar (116 - 464 psig)
• Left Differential: 0.7 – 4 bar
• Right Differential: Fixed 4 bar

Electrical Specifications

• AC15: 10 A / 400 V
• AC1 / AC3: 16 A / 400 V
• DC13: 12 W / 220 V
• Terminal D: 50 VA / 400 V
• Starting Current (LR): 112 A / 400 V
• Short-Circuit Protection: 16 A fuse
• Insulation Voltage: 400 V (EN 60947)
• Impulse Withstand: 4 kV

Operation and Durability

• Ambient Temperature: -40 °C ~ +65 °C
• Short-Term Maximum: 80 °C (120 minutes)
• Protection Class: IP30 (NEMA 1 equivalent)
• MWP Left: 17 bar (245 psig)
• MWP Right: 35 bar (510 psig)
• Test Pressures: Left: 20 bar, Right: 35 bar

Refrigerant Compatibility

• R134a, R22, R404A, R407C/F/H, R410A, R448A, R449A/B, R507A, R513A, R515B, R1234yf, R1234ze(E), R452A, R454C, R438A and others

Certificates and Compliance

• Approvals: CE, c UL us, EAC, CCC, DNV, GL, BV, RINA, LR, RMRS, CMIM, PZH
• RoHS Compliance: China and EU RoHS
• SCIP Dossier No: b1323c86-8856-44cc-b1c6-6849abe37ee4

Physical Information

• Gross Weight: 0.5 kg
• Net Weight: 0.469 kg
• Volume: 0.861 L
• EAN: 5702422032946

Applications

The Danfoss KP15 (060-126466) has been developed for use in refrigeration, air conditioning and industrial systems requiring high-precision pressure control. Thanks to its dual contact arrangement and separate reset functions, it provides maximum flexibility in terms of system monitoring and safety.
