Danfoss CPCE 12 Hot Gas Bypass Regulator – 1/2" ODF, Pilot Operated, 0-6 bar Setting Range

Product Description

The Danfoss CPCE 12 hot gas bypass regulator is a pilot-operated valve solution designed to prevent the evaporator from freezing even at minimum load and to provide a constant evaporating pressure. With high-precision control and a wide temperature range, it offers reliable performance in commercial refrigeration systems.

Technical Specifications

• Product Code: 034N0082
• Type: CPCE 12
• Connection Type: Solder (ODF)
• Connection Size (Inlet / Outlet): 1/2 inch (12 mm)
• Pilot Line Inlet: 7/16"-20 UNF (flare)
• Setting Pressure Range: 0 – 6 bar
• Factory Setting: 0.4 bar (5.8 psig)
• Differential Pressure: 18 bar
• Maximum Working Pressure: 28 bar (406 psig)
• Maximum Test Pressure: 31 bar (450 psig)
• Operating Temperature: -50°C to +140°C

Cooling Capacities

• R404A / R507A: 16.4 kW (6.3 TR)
• R134a: 7.9 kW (4.3 TR)
• R22: 17.4 kW (6.2 TR)
• R407C: 19 kW (6.7 TR)

Suitable Refrigerants

The CPCE 12 model is compatible with many HFC, HFO and HC refrigerants such as R134a, R22, R404A, R407C, R448A, R449A, R507A, R513A, R1234ze(E), R290 and R452A.

General Features

• Product Group: Pressure and Temperature Regulating Valves
• Pilot Line Connection: External, flared
• Flow Direction: Indicated by an embossed one-way arrow
• Approvals: UL, CE, EAC, RoHS
• Service Status: Serviceable, spare parts support available
• EAN: 5702422007821
